PureVolt Double Crimp Heat Shrink Female Blade Terminal - .250 in. - 22-16 AWG - Pink - 10-Pack

The Purevolt 0.250" female blade terminal is a quality product specifically designed for wire sizes 22 AWG to 16 AWG (0.5 to 1.5 mm²).

With its double crimp design and heat shrink tubing, our female blade terminal connector provides maximum insulation for a secure and convenient electrical connection that can last for years. It is an ideal choice for durable, secure connections with electrical applications requiring 22 to 16 AWG wire.

Features :

• Double Crimp / Double Barrel
• Heat shrink tubing design provides maximum insulation for protection against moisture, dust and corrosion
• Designed for wire sizes: 22 AWG, 20 AWG, 18 AWG and 16 AWG (0.5 to 1.5 mm²)
• Blade size (width x thickness): 0.250" x 0.032" (6.4 mm x 0.8 mm)
• Color : Pink
• 10 Pack Heat Shrink Female Blade Terminals for 22-16 AWG Wire

Dimensions:

• D1: 1.90 mm (0.075")
• B: 6.70 mm (0.264")
• L: 31.00 mm (1.220")
• T: 0.40 mm (0.016")
