LED Module for Backlit - 2 LED - 12 VDC - 6000K - IP65

• 8-15 cm thickness small size channel letter and light box back lighting
• Best for 10 cm depth small size light box and channel letter backlighting

Specifications:

• Model : MA542F-W
• LED Type : SMD 2835
• LED Quantity : 2 pcs
• Color : cold white
• Concatenation : 20 modules
• Power : 1.2 W ± 10%
• Input Voltage : 12 VDC
• Input Current : 0.1 A ± 10%
• Driving Mode : constant current
• Protection Level : IP65 (Water Resistant)
• Color Temperature (CCT) : 6000K ± 5%
• Color Rendering Index (CRI) : 70 – 90
• Luminous Flux (ϴ) : 112 lumens
• Visual Angle : 170°
• Working Temperature : -20°C ~ +45°C
• Storage Temperature : -30°C ~ +60°C
• Dimensions : 54 mm x 18 mm x 7.2 mm
